Steering Wheel High Pressure PU Machine
HF PU flex fatigue tester for shoe sole & auto foam, 0-180° bend,10-300 cycles/min, ISO/ASTM compliant, factory QC device, supply standard flex test report
±0.5% Accuracy
Ratio precision
loT Ready
Remote monitoring
30% Energy Save
vs.conventional
2-4 Components
Flexible config
Product Overview
Specially designed for the integral skin foaming production of automotive steering wheels, armrests and interior parts.
This high-pressure PU machine is purpose-built for the integral skin foaming production of automotive steering wheels, armrests, and interior components. The 1A1B two-component system with independent temperature control and circulation stirring ensures consistent material quality. Integral skin foaming molding delivers a smooth and flawless steering wheel surface with comfortable hand feel. Precision metering control with ≤±0.3% dosing accuracy ensures accurate product size, suitable for precision molds of steering wheels. The environmentally friendly solvent-free automatic air purge cleaning system complies with automotive interior environmental protection standards, ensuring odor-free finished products. With compact and flexible equipment design, the machine is suitable for small-batch, multi-style steering wheel production. The system meets the core requirements of smooth surface, moderate hardness, wear resistance, environmental protection and odorless for automotive interior parts, supporting standardized production in the auto parts industry.
Operation Workflow
Raw Material Preparation
Prepare polyether polyol and isocyanate according to the target mix ratio (100:50~70). Ensure both components are properly conditioned for integral skin foam formulation.
Tank Loading & Temperature Setting
Load polyol into Tank A and isocyanate into Tank B. The 1A1B independent temperature control system maintains 20–45°C with circulation stirring for uniform material consistency.
High-Pressure Metering & Mixing
The PLC-controlled dosing system (accuracy ≤±0.3% full dynamic range) dispenses materials precisely. The mixing head operates at 6000–10000 r/min under 10–18 MPa pressure for homogeneous blending.
Integral Skin Foaming & Molding
Inject the mixed material into the steering wheel precision mold. Integral skin foaming forms a smooth, flawless surface with moderate hardness and comfortable hand feel, meeting automotive interior quality standards.
Request a Customized Steering Wheel Foaming Solution
Get a QuoteTechnical Specifications
Standard configuration parameters for the steering wheel high-pressure PU machine. Customizations including tank capacity are available upon request.
| Technical Parameter | HF-HPM-1A1B-SteeringWheel |
|---|---|
| Pouring Rate | 50～800 g/s |
| Mix Ratio | Polyether: Isocyanate = 100:50~70 |
| Tank Capacity | 100L / 150L (Optional, Per Tank) |
| Mixing Head Speed | 6000～10000 r/min |
| Dosing Accuracy | ≤±0.3% (Full Dynamic Range) |
| Tank Configuration | 1A1B Two-Component Independent Temp Control + Circulation Stirring |
| Temperature Control | 20～45℃ |
| Mixing Pressure | 10～18 MPa |
| Vacuum Defoaming | None |
| Cleaning System | Automatic Air Purge Cleaning (Solvent-Free & Eco-Friendly) |
| Power | 5.5～7.5 kW |
| Control System | PLC + Touch Screen + Multi-Formula Storage |
| Application System | Polyurethane Integral Skin Foam System |
| Warranty | 1 Year |
| Certification | CE, ISO9001 |
Key Features & Advantages
Engineered for precision, comfort, and environmental compliance in automotive steering wheel production.
Integral Skin Foaming Molding
Produces a smooth and flawless steering wheel surface with comfortable hand feel, meeting automotive interior quality standards.
Precision Metering Control
Dosing accuracy ≤±0.3% ensures accurate product size, suitable for precision molds of steering wheels and interior parts.
Environmentally Friendly Solvent-Free Cleaning
Automatic air purge cleaning system requires no solvents, in line with automotive interior environmental protection standards and ensuring odor-free finished products.
Compact & Flexible Equipment Design
Suitable for small-batch, multi-style steering wheel production, enabling efficient changeovers between different models and specifications.
High-Pressure Homogenization
Mixing pressure of 10–18 MPa with high-speed mixing (6000–10000 r/min) ensures homogeneous material blending for consistent product quality.
Intelligent PLC Control with Multi-Formula Storage
PLC + touch screen interface with multi-formula storage simplifies operation and enables rapid changeovers between different steering wheel styles and formulations.
Enhance Your Steering Wheel Production with High-Pressure Integral Skin Foaming
Our engineering team specializes in automotive interior foaming solutions. Contact us to discuss your specific steering wheel models, production capacity needs, and environmental compliance requirements.
Application Scenarios
Steering wheels, armrests, and interior parts with integral skin polyurethane foam.
